PVC XLPE Insulated Medium Voltage Low Voltage Copper Cable

Overview

Basic Info.

Model NO.	UL 1007
Material Shape	Round Wire
Range of Application	Heat Resistance
Certification	ISO9001, CCC, RoHS
Brand	Werlg
Core Number	Single Core
Size	30 AWG
Colour	Red, Orange, Yellow, Brown, Purple, Black
Temperature	80 Centidegree
Voltage	300V
UL Certificate	UL 1007
Transport Package	PE and Carton
Specification	ROHS, UL
Trademark	WERLG
Origin	Zhejiang China
HS Code	8544492100
Production Capacity	200000meters/Day

Product Description

Product Description

PVC XLPE Insulated Medium Voltage Low Voltage Copper Cable
TECHNICAL DATA
Rated voltage: 300V
Rated temperature:-40ºC~+80ºC
Conductor: Tinned or bare, strand or solid copper
Insulator: PVC
OD Tolerance: ±0.05mm
Colour: white, blue, red, black, brown, orange, purple, gray, yellow, green, transparent, yellow-green, etc
CHARACTERISTIC
Flexible, easy assemble, cold resistance, stable performance, UL 758, RoHs compliance.
APPLICATION
Apply to household appliance, illumination & lighting & headlamp, electric machines, temperature sensor, metallurgy chemical series, motor cars & ships, electrical installation.

Product Parameters

UL1007	Conductor		OverDiamter±0.05mm²	Insulator			Technical Data		Packing(m/roll)
Size	ConductorConstructionNo./mm	Diametermm		Material	AverageThicknessmm	Colour	Temperature Range(ºC)	Nominal voltage
32 AWG	7/0.08	0.24	1.O5	PVC	0.403	red,yellow,blue,green,black,white,purple,brown,orange,yellow-green,transparent	80ºC	300V	610
30 AWG	7/0.1	0.3	1.11	PVC	0.402				610
28 AWG	7/0.127	0.38	1.19	PVC	0.401				610
26 AWG	7/0.16	0.48	1.29	PVC	0.401				610
24 AWG	11/0.16	0.61	1.42	PVC	0.404				610
22 AWG	17/0.16	0.76	1.57	PVC	0.404				610
20 AWG	26/0.16	0.94	1.75	PVC	0.404				305
18 AWG	41/0.16	1.18	1.99	PVC	0.403				305
16 AWG	26/0.254	1.49	2.29	PVC	0.397				305
14 AWG	41/0.254	1.86	2.68	PVC	0.401				305
